Panasonic TX-L32E30B - A-BOARD Conductor View (Top); A-BOARD Conductor Layout (Top View)

A
B
C
D
E
5
4
3
2
1
Conductor Views
A-BOARD TNPH0931 - TOP
IC’S
TRAN’S
IC4700 4B
Q0900 4D
IC4900 1A
Q3102 4A
IC5000 3E
Q3103 4A
IC5205 4E
Q3104 3A
IC6700 2C
Q3105 3A
IC6750 1C
Q4704 5A
IC6765 1C
Q4709 3B
IC8000 2D
Q8100 2E
IC8200 2E
Q8101 2E
IC8201 1D
Q8102 2E
IC8403 3D
IC8404 3D
DIODE’S
IC8702 1D
D1006 2A
IC8901 4E
IC8902 4E
66
