Intermediate Frequency:
Video/Audio
Video 38,9MHz, 33,9MHz
Audio 33,4MHz (B/G), 33,16MHz (A2)
33,05MHz (NICAM B/G, D/K, L’)
32,4MHz (D/K), 32,66MHz (CZ STEREO)
40,4MHz (L’), 39,75MHz (L’ NICAM)
32,90 I, 32.35MHz (NICAM)
Colour 34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM)
38,3MHz, 38,15MHz (SECAM L’)
Terminals:
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin) 0.7V p-p 75Ω
S-video IN (21-pin) Y: 1V p-p 75Ω
C:0.3V p-p 75Ω
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (21 pin) 1.0V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
RGB (21 pin) 0.7V p-p 75Ω
S-video IN (21-pin) Y: 1.0V p-p 75Ω
C:0.3V p-p 75Ω
AV2 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV3 Video RCA PIN Type x 1 Y:1V p-p 75Ω
AUDIO IN Audio RCA PIN Type x 2 500mV rms 1kΩ
COMPONENT Video RCA PIN Type x 3 Y:1V p-p 75Ω (including synchronization)
Pb, Pr: ±0,35V p-p 75Ω
AUDIO IN Audio RCA PIN Type x 2 500mV rms 1kΩ
AUDIO OUT Audio (RCAx2) 500mV rms 1kΩ (high Impedance)
HDMI1/2/3 Type A Connector
HDMI1/3 :HDMI (Version 1.3a with Deep Colour)
HDMI 2 :HDMI (Version 1.4 with Audio Return Channel) and
HDMI (Version 1.3a with Deep Colour)
PC HIGH-DENSITY D-SUB 15PIN R,G,B: 700mV p-p 75Ω
HD,VD/TTL Level 2-5V p-p (high impedance)
CARD SLOT SD CARD slot ×1
Common Interface slot ×1 (Complies with CI+)
DIGITAL AUDIO OUT PCM / Dolby Digital / DTS , Fiber optic
LCD screen: L5EDD9T00027 [L5EDD8T00017]
1920 x 1080 XGA, 16:9
Visible Diagonal 940mm [800mm]
Audio Output: 20W (2x10W), 10% THD
Headphones: 3.5mm (M3), 8Ω Impedance
Accessories supplied : Remote Control 2 x R6 (UM3) Batteries
Dimensions:
Height: Width: Depth:
Including TV stand 621mm 915mm 287mm
[551mm] [798mm] [217mm]
TV set only 577mm 915mm 87mm
[511mm] [798mm] [83mm]
Net weight:
Including TV stand 15.5kg [11.5kg]
TV set only 13.0kg [9.5kg]
Specifications are subject to change without notice. Weights and dimensions shown are approximate.
2
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
Warning
