Panasonic TX-P50C2B - Page 104

104
IC16786 MIP3910MSSCF IC 1
IC16787 C0DBZYY00352 IC 1
IC17101 C0JBAU000043 IC 1
IC17202 C0JBAU000043 IC 1
IC17203 C0JBAZ002692 IC 1
L16011 G0ZZ00002183 PEAKING COIL 1
L16012 G0ZZ00002183 PEAKING COIL 1
L16013 G0ZZ00002183 PEAKING COIL 1
L16014 G0ZZ00002183 PEAKING COIL 1
L16103 G0ZZ00002183 PEAKING COIL 1
L16303 G0C471MA0049 PEAKING COIL 1 PAVCCZ
L16401 G0C1R1K00002 PEAKING COIL 1 PAVCCZ
L16411 G0C1R1K00002 PEAKING COIL 1 PAVCCZ
L16421 G0ZZ00002183 PEAKING COIL 1
L16422 G0ZZ00002183 PEAKING COIL 1
L16423 G0ZZ00002183 PEAKING COIL 1
L16424 G0ZZ00002183 PEAKING COIL 1
L16472 G0ZZ00002183 PEAKING COIL 1
L16698 G0C681MA0065 PEAKING COIL 1
L16851 G0ZZ00002183 PEAKING COIL 1
PC16191 B3PBA0000496 IC 1
PC16192 B3PBA0000223 IC 1
PC16461 B3PBE0000054 IC 1
PC16480 B3PBA0000223 IC 1
PC16603 B3PBA0000223 IC 1
PC16684 B3PBA0000496 IC 1
PC16685 B3PBA0000496 IC 1
PC16722 B3PBA0000223 IC 1
PC16723 B3PBA0000223 IC 1
PC16896 B3PBA0000223 IC 1
PC16897 B3PBA0000223 IC 1
Q16001 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16002 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16021 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16022 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16101 B1CFRM000008 FET 1
Q16102 B1CFRM000008 FET 1
Q16141 B1HFPFA00001 TRANSISTOR 1
Q16161 B1HFPFA00001 TRANSISTOR 1
Q16191 B1HFPFA00001 TRANSISTOR 1
Q16280 B1ABCF000231 TRANSISTOR 1
Q16401 B1JAEQ000010 TRANSISTOR 1 PAVCCZ
Q16402 B1JAEQ000010 TRANSISTOR 1 PAVCCZ
Q16421 B1JAEP000014 TRANSISTOR 1 PAVCCZ
Q16422 B1JAEP000014 TRANSISTOR 1 PAVCCZ
Q16441 DG3D5010CSLW ZENER DIODE 1 PAVCCZ
Q16451 B1JAEP000012 TRANSISTOR 1
Q16471 B1ABCF000231 TRANSISTOR 1
Q16490 B1CBGD000001 FET 1
Q16501 B1HFPFA00001 TRANSISTOR 1
Q16521 B1HFPFA00001 TRANSISTOR 1
Q16531 B1HFPFA00001 TRANSISTOR 1
Q16551 B1HFPFA00001 TRANSISTOR 1
Q16601 B1CERR000025 FET 1
Q16602 DSC2001Q0L TRANSISTOR 1
Q16603 DSA2001S0L TRANSISTOR 1
Q16606 DSC2001Q0L TRANSISTOR 1
Q16607 B1CBGD000001 FET 1
Q16621 B1JADN000004 TRANSISTOR 1
Q16661 B1JAER000010 TRANSISTOR 1
Q16662 DSC2001Q0L TRANSISTOR 1
Q16663 DSA2001S0L TRANSISTOR 1
Q16670 B1ADCN000007 TRANSISTOR 1
Q16671 B1ABCF000231 TRANSISTOR 1
Q16672 B1CBGD000001 FET 1
Q16675 B1ADCN000007 TRANSISTOR 1
Q16676 B1ABCF000231 TRANSISTOR 1
Q16701 B1ADCN000007 TRANSISTOR 1
Q16702 B1ABCF000231 TRANSISTOR 1
Q16762 B1HFPFA00001 TRANSISTOR 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
Q16801 DSA2001S0L TRANSISTOR 1
Q16810 B1ABCF000231 TRANSISTOR 1
Q16815 B1ABCN000007 TRANSISTOR 1
Q16816 DSC2001Q0L TRANSISTOR 1
Q16817 DSC2001Q0L TRANSISTOR 1
Q16818 B1CBGD000001 FET 1
Q16876 B1ABCF000231 TRANSISTOR 1
Q16885 B1CFNG000001 FET 1
Q16920 B1ABCN000007 TRANSISTOR 1
Q16921 B1ABCN000007 TRANSISTOR 1
Q16930 DSC2001Q0L TRANSISTOR 1
Q16931 B1ABCN000007 TRANSISTOR 1
Q16932 DSC2001Q0L TRANSISTOR 1
R16001 ERJT08J7R5V M 7.5OHM,J,
0.33W
1
R16002 ERJT08J7R5V M 7.5OHM,J,
0.33W
1
R16021 ERJT08J7R5V M 7.5OHM,J,
0.33W
1
R16022 ERJT08J7R5V M 7.5OHM,J,
0.33W
1
R16101 ERJT06J221V M 220
OHM,F,0.25W
1
R16102 ERJT06J221V M 220
OHM,F,0.25W
1
R16103 ERJT06J100V M 10 OHM,F,0.25W 1
R16104 ERJT06J100V M 10 OHM,F,0.25W 1
R16105 ERJ8GEYJ474 M 470KOHM, J,1/
8W
1
R16109 ERJT06J100V M 10 OHM,F,0.25W 1
R16116 D0GB473JA057 M 47KOHM,J,1/10W 1
R16131 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R16132 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R16134 ERJT06J750V M 75 OHM,F,0.25W 1
R16137 ERJT08J1R0V M 1.8OHM,J,
0.33W
1
R16141 ERJT06J100V M 10 OHM,F,0.25W 1
R16143 D0GB473JA057 M 47KOHM,J,1/10W 1
R16161 ERJT06J100V M 10 OHM,F,0.25W 1
R16163 D0GB473JA057 M 47KOHM,J,1/10W 1
R16191 ERJ6GEYJ151V M 150 OHM,J,1/
10W
1
R16192 D0GB103JA057 M 10K OHM J 1/
10W
1
R16193 ERJ6GEYJ750 M 75 OHM,J,1/10W 1
R16195 ERJT08J1R0V M 1.8OHM,J,
0.33W
1
R16241 EXB38V470J RESISTOR ARRAY 1
R16242 EXB38V472JV RESISTOR ARRAY 1
R16280 D0GB222JA041 M 2.2KOHM,J,1/
10W
1
R16281 D0GB103JA057 M 10K OHM J 1/
10W
1
R16282 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R16283 D0GB473JA057 M 47KOHM,J,1/10W 1
R16284 D0GB224JA041 M 2.2KOHM,J,1/
10W
1
R16285 EXB38V623J RESISTOR ARRAY 1
R16289 ERJT08J334V M
330KOHM,F,0.33W
1
R16290 ERJT08J334V M
330KOHM,F,0.33W
1
R16307 ERJ6RBD623 M 62KOHM,J,1/10W 1
R16309 ERG1FJS333D M 33KOHM, J, 1W 1
R16318 ERJ6RBD563 M 56KOHM, J,1/
10W
1
R16319 ERJ6RBD242 M 2.4KOHM,J,1/
10W
1
R16320 ERJ14YJ683 M 68KOHM, 1/2W 1
R16330 D0GB102JA041 M 1KOHM,J,1/10W 1
R16332 D0GB474JA041 M 470KOHM,J,1/
10W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
