Panasonic TY-FB9FDD

Ref. No. Part No. Part Name &
Description
Pcs Remarks
C3021 ECJ1VF1H103Z C 0.010UF, Z,
50V
1
C3105-17 ECJ1XF1C104Z C 0.1UF, Z, 16V 13
C3118 ECJ1VF1C105Z C 1UF, Z, 16V 1
C3141 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3142 ECJ1VF1C105Z C 1UF, Z, 16V 1
C3143 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3144 ECJ1VF1C105Z C 1UF, Z, 16V 1
C3201 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3202 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3203 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3204 ECJ1VC1H100C C 10PF, C, 50V 1
C3205 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3206 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3207 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3208 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3209 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3210 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3211 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3212 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3213 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3214 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3215 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3216 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3217 ECJ1XB1H102K C 1000UF, Z, 50V 1
C3501 ECJ1VF1C105Z C 1UF, Z, 16V 1
C3511 ECJ1VF1C105Z C 1UF, Z, 16V 1
C3551 EEEHB1C470P C 47PF, J, 16V 1
C3552 ECJ1VF1H103Z C 0.010UF, Z,
50V
1
C3901-04 EEEHB1C470P C 47PF, J, 16V 4
C3905 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3911,12 ECJ1XF1C104Z C 0.1UF, Z, 16V 2
C3913 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3915 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3921 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3922 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3923 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3924 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3925 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3926 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3927 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3928 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3929 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3930 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3931 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3932 ECJ3XB1C106M C 1.0UF, K, 16V 1
C3933 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C3934 ECJ3XB1C106M C 1.0UF, K, 16V 1
D3001-10 EZJZ0V80008B VARISTOR 10
D3011 B0HCMM000014 DIODE 1
D3021-24 MA3056M ZENER DIODE 4
D3025 B0HCMM000014 DIODE 1
FL3021 ELKE103FA NOISE FILTER 1
FL3901-08 ELKE103FA NOISE FILTER 8
H0 K1KA09AA0150 9P CONNECTOR 1
H1 K1KA80B00037 80P CONNECTOR 1
IC3001 TVRP127 IC 1
IC3101 C1AB00002291 IC 1
IC3102 C0JBAZ002269 IC 1
IC3103 JLC1562BF MOS IC (MICON
LSI)
1
IC3105 C0JBAZ002269 IC 1
IC3201 C0ZBZ0001411 IC 1
IC3901 TVRP125 IC 1
IC3902 C0JBAZ002344 IC 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
IC3906 C0JBAB000671 IC 1
JK3001 K1FB124B0025 CONNECTOR 1
JK3501 K2HC103B0105 JACK 1
JS3501-03 ERJ6GEY0R00 M 0 OHM, 1/10W 3
L3551 G1C100K00020 INDUCTION COIL 1
L3552,53 EXC3BB221H BEAD CHOKE 2
Q3100,01 2SD601A TRANSISTOR 2
Q3501 2SD601A TRANSISTOR 1
Q3511 2SD601A TRANSISTOR 1
R3001 ERJ3GEYJ562 M
5.6KOHM,J,1/16W
1
R3022 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R3023,24 ERJ3GEYJ472 M
4.7KOHM,J,1/16W
2
R3025,26 ERJ3GEYJ560 M 56 OHM,J,1/16W 2
R3105 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R3108-13 EXB38V220J RESISTOR ARRAY 6
R3114-18 ERJ3GEYJ330 M 33 OHM,J,1/16W 5
R3119-24 EXB38V220J RESISTOR ARRAY 6
R3125 ERJ3EKF3900 M 390 0HM, 1/16W 1
R3131 ERJ3GEYJ330 M 33 OHM,J,1/16W 1
R3132 ERJ3GEYJ272 M
2.7KOHM,J,1/16W
1
R3133 ERJ3GEYJ330 M 33 OHM,J,1/16W 1
R3134-36 ERJ3GEYJ272 M
2.7KOHM,J,1/16W
3
R3137,38 ERJ3GEYJ330 M 33 OHM,J,1/16W 2
R3139 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R3142-44 ERJ3GEYJ330 M 33 OHM,J,1/16W 3
R3146-48 ERJ3GEYJ472 M
4.7KOHM,J,1/16W
3
R3151,52 ERJ3GEY0R00 M 0 OHM, 1/16W 2
R3153 ERJ3GEYJ330 M 33 OHM,J,1/16W 1
R3155,56 ERJ3GEYJ330 M 33 OHM,J,1/16W 2
R3157 ERJ3GEYJ472 M
4.7KOHM,J,1/16W
1
R3160 ERJ3GEYJ472 M
4.7KOHM,J,1/16W
1
R3163 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R3166,67 ERJ3GEYJ220 M 22 OHM,J,1/16W 2
R3168,69 ERJ3GEYJ472 M
4.7KOHM,J,1/16W
2
R3173 ERJ3GEYJ272 M
2.7KOHM,J,1/16W
1
R3175 ERJ3GEYJ272 M
2.7KOHM,J,1/16W
1
R3178,79 ERJ3GEYJ330 M 33 OHM,J,1/16W 2
R3181-86 ERJ3GEYJ103 M 10KOHM,J,1/16W 6
R3188 ERJ3GEYJ330 M 33 OHM,J,1/16W 1
R3202,03 ERJ3GEYJ103 M 10KOHM,J,1/16W 2
R3209 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R3210-28 ERJ3GEY0R00 M 0 OHM, 1/16W 19
R3229 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R3501 ERJ3GEYJ184 M
180KOHM,J,1/16W
1
R3502 ERJ3GEYJ101 M 100
OHM,J,1/16W
1
R3503 ERJ3GEYJ153 M 15KOHM,J,1/16W 1
R3504 ERJ3GEYJ333 M 33KOHM,J,1/16W 1
R3505 ERJ3GEYJ101 M 100
OHM,J,1/16W
1
R3506 ERJ3GEYJ102 M 1KOHM,J,1/16W 1
R3507 ERJ3GEYJ101 M 100
OHM,J,1/16W
1
R3511 ERJ3GEYJ184 M
180KOHM,J,1/16W
1
R3512 ERJ3GEYJ101 M 100
OHM,J,1/16W
1
R3513 ERJ3GEYJ153 M 15KOHM,J,1/16W 1
