3WAY SYSTEM
Outdoor Unit Maintenance Remote Controller
3 - 10
3
4. Monitoring Operations
N
Display of unit No. 1 (main unit)
DN Description Remarks
Intake temp. °C
E1 °C
E2 °C
E3 °C Indoor unit
Discharge temp. °C
Discharge temp. setting °C
Indoor unit electronic control valve position STEP
Discharge temp. 1 °C
Discharge temp. 2 °C
High-pressure sensor temp. °C
Heat exchanger gas 1 °C
Heat exchanger liquid 1 °C
Heat exchanger gas 2 °C
Heat exchanger liquid 2 °C
Outdoor air temp. °C
Not used
Inverter primary current A
CT2 A Outdoor unit
MOV1 pulse STEP
MOV2 pulse STEP
Discharge temp. 3 °C
CT3 A
MOV3 pulse STEP
MOV4 pulse STEP
Heat exchanger gas 3 °C
Heat exchanger liquid 3 °C
Low-pressure sensor temp. °C
Receiver temp. °C
Oil 1 °C
Oil 2 °C
Oil 3 °C
Actual operating frequency Hz
NOTE
0A and subsequent items are outdoor unit data. 0A – 22 are for unit No. 1.
2A – 42 are for unit No. 2. 4A – 62 are for unit No. 3.
