Active Optical Connector V Series
–2–
ACCTB69E 201602-T
PRODUCT TYPES
1. Integrated cable and plug
2. Receptacle (PC board side)
SPECIFICATIONS
1. Rated specifications
Notes: 1. When performing AC coupling, the input common mode voltage is 0 to 1.8 V.
2. Input data pattern is PRBS 2
7
-1.
Rjpp is equivalent to BER 10
-12
.
2. Use conditions
Transmission rate Transmission specifications Cable length Part No. Packing quantity
20 Mbps to 6 Gbps Bi-direction, 1 channel
50 mm AYG4V10565M1
10 pieces300 mm AYG4V13065M1
1 m AYG4V1A065M1
50 mm AYG4V10565M3
100 pieces300 mm AYG4V13065M3
1 m AYG4V1A065M3
Part No. Packing quantity
Receptacle
AXK6S20447M1 20 pieces
AXK6S20447M3 200 pieces (reel)
Item Min. Typical Max. Unit Condition
Supply voltage 3.2 3.3 3.4 V —
Power consumption — — 230 mW Bi-direction 1channel
Transmission rate 0.02 — 6 Gbps 8b/10b coding
Input/output characteristic impedance 80 100 125 Ω —
Differential input voltage 200 — 1200 mV —
Input common mode voltage 150 — 340 mV Note 1)
Input total jitter — — 0.24 UI Note 2)
Input rise-time — — 0.30 UI —
Input fall-time — — 0.30 UI —
Differential output voltage 150 220 275 mV Note 2)
Output common mode voltage 150 250 275 mV Note 2)
Output rise-time — — 0.50 UI Note 2)
Output fall-time — — 0.50 UI Note 2)
Output total jitter — — 0.60 UI Note 2), Dj + Rjpp
Item Performance Remarks
Operating ambient temperature 0°C to +70°C No icing or condensation.
Storage temperature
-20°C to +50°C (Packaged form)
-20°C to +85°C (Product only)
No icing or condensation.
Relative humidity 20% to 80%RH No condensation.
Electrical static discharge 2kV
Applied 3 times on the external shell
C = 100pF, R = 1.5kΩ
C = 150pF, R = 330Ω
Immunity Conformed to IEC61000-6-2 standard —
Electromagnetic interference Conformed to VCCI class B standard —
