Setup
Inserting/removing a disc
23
LSQT1184
Inserting/removing a disc
When inserting or removing the disc, fit the charged battery pack or connect the AC adaptor to the
unit. The cover of the disc compartment will not open unless the unit is powered.
1 Slide the DISC EJECT lever once and
release it.
A few moments after the ACCESS/PC lamp blinks,
the cover of the disc compartment will open slightly.
2 Open the cover of the disc compartment by hand and insert/remove
the disc.
∫ Inserting disc
Fit the disc onto the spindle in the centre.
A Recording/playback side
B Pickup lens
∫ Removing disc
While pressing down on the spindle, grasp the edge of the disc and gently lift it out.
3 Push the section marked “PUSH CLOSE” on the cover of the disc
compartment to close the cover.
AB
Click!
