23
LSQT1328
Before using
6
Inserting/removing an SD
card
Caution:
If the SD card is inserted or removed while the power is on, this unit may malfunction or the data
recorded on the SD card may be lost.
1 Set the mode dial to OFF and
remove the battery.
≥ Check that the status indicator has gone off.
2 Open the SD card slot cover.
3 Insert/remove the SD card.
≥ Press the SD card straight in as far as it will go.
≥ Press the centre of the SD card and then pull it
straight out.
4 Securely close the SD card slot
cover.
A
2
B
1
A Label side
SD card access lamp [ACCESS
CARD] B
≥ When this unit is processing data, the lamp
lights up.
≥ When lamp is on, do not:
sRemove the SD card
sOperate the mode dial
sRemove the battery or disconnect the
AC adaptor
≥ Performing the above while lamp is on may
result in damage to data/SD card or this
unit.
