Specifications
74
Specifications
TX-L24C3E, TX-L24C3ES
Power Source AC 220-240 V, 50Hz
Rated Power Consumption 72 W
Standby Power
Consumption
0.3 W
6.7 W (With monitor out recording)
Dimensions (W × H × D)
620 mm × 437 mm × 187 mm (With Pedestal)
620 mm × 404 mm × 99 mm (TV only)
Mass
6.5 kg Net (With Pedestal)
6.0 kg Net (TV only)
Display panel
Aspect Ratio 16:9
Visible screen size
61 cm (diagonal)
532 mm (W) × 299 mm (H)
Number of pixels 1,049,088 (1,366 (W) × 768 (H))
Sound
Speaker (120 mm × 42 mm) × 2, 8 :
Audio Output 10 W (5 W + 5 W), 10% THD
Headphones M3 (3.5 mm) stereo mini Jack × 1
Receiving Systems /
Band name
Check the latest information
on the available services at the
following website.
(English only)
http://panasonic.jp/support/
global/cs/tv/
PAL B, G, H, I,
SECAM B, G,
SECAM L, L’
VHF E2 - E12
VHF A - H (ITALY)
CATV (S01 - S05)
CATV S11 - S20 (U1 - U10)
VHF H1 - H2 (ITALY)
UHF E21 - E69
CATV S1 - S10 (M1 - M10)
CATV S21 - S41 (Hyperband)
PAL D, K,
SECAM D, K
VHF R1 - R2 VHF R3 - R5
VHF R6 - R12 UHF E21 - E69
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC (AV input only) Playback from NTSC Video recorders (VCR)
DVB-T Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
DVB-C Digital cable services (MPEG2 and MPEG4-AVC(H.264))
Aerial input VHF / UHF
Operating Conditions
Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
