2.2 WH-SDC05E3E5 WH-UD05EE5
Item Unit Outdoor Unit
Performance Test Condition
EN 14511
Condition
(Ambient/Water)
A35W7
kW 4.50
BTU/h 15300
Cooling Capacity
kcal/h 3870
W/W 2.69
Cooling EER
kcal/hW 2.32
Condition
(Ambient/Water)
A7W35 A2W35
kW 5.00 4.20
BTU/h 17100 14300
Heating Capacity
kcal/h 4300 3610
W/W 4.63 3.11
Heating COP
kcal/hW 3.98 2.67
Condition
(Ambient/Water)
A35W7 A7W35 A2W35
dB (A) Cooling: 48 Heating: 48 —
Noise Level
Power Level dB Cooling: 66 Heating: 66 —
Air Flow
m
3
/min (ft
3
/min)
Cooling: 39.3 (1390)
Heating: 34.4 (1310)
Refrigeration Control Device
Expansion Valve
Refrigeration Oil
cm
3
FV50S (450)
Refrigerant (R410A)
kg (oz) 1.20 (42.4)
Height
mm (inch) 622 (24-1/2)
Width
mm (inch) 824 (32-15/32)
Dimension
Depth
mm (inch) 298 (11-24/32)
Net Weight
kg (lbs) 39 (86)
Liquid
mm (inch) 6.35 (1/4)
Pipe Diameter
Gas
mm (inch) 12.70 (1/2)
Standard Length
m (ft) 7 (23.0)
Pipe Length Range
m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height Difference
m (ft) 5 (16.4)
Additional Gas Amount
g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less
m (ft) 10 (32.8)
Type
Hermetic Motor
Motor Type
Brushless (4-poles)
Compressor
Rated Output
kW 0.90
Type
Propeller Fan
Material
PP
Motor Type
DC (8-poles)
Input Power
W —
Output Power
W 40
Fan
Fan Speed
rpm
Cooling: 980
Heating: 860
Fin material
Aluminium (Pre Coat)
Fin Type
Corrugated Fin
Row × Stage × FPI
2 × 28 × 17
Heat Exchanger
Size (W × H × L)
mm 36.4 × 588 × 827.7 : 856.3
