41
ON: Displays black-and-white images.
OFF (default): Displays color images.
Note:
If a subject is always moving or the
screen is occupied with a uniform color,
brightness determination may be not per-
formed successfully because the bright-
ness is merely determined by information
from the CCD image sensor. When
"AUTO2" is selected, the wave length of
the light source shall be 800 nm or
longer.
Step 3
Move the cursor to "LEVEL" and select a
brightness level at which switching between
color and black-and-white images is per-
formed from the following:
LOW: Switches from color to black-and-white
images when the ambient brightness
(illuminance) of the camera is approx.
0.1 lx or less. (when the AGC MAX level
is set to the top end.)
HIGH (default): Switches from color to black-
and-white images when the ambient
brightness (illuminance) of the camera is
approx. 0.2 lx or less. (when the AGC
MAX level is set to the top end.)
Step 4
Move the cursor to "DURATION TIME" and
select a time for switching between color and
black-and-white images from the following:
(Default: 30 seconds)
10 sec.- 30 sec.- 60 sec.- 300 sec.
(S) (L)
Step 5
Move the cursor to "BURST (BW)", and
decide whether or not to provide a burst sig-
nal output in the black-and-white mode with
use of "ON" or "OFF".
ON (default): Provides a burst signal output.
OFF: Does not provide any burst signal out-
put.
Notes:
• The auto back focus function also allows
users to correct out of focus when
changing between color and black-and-
white images. (☞ page 45)
• Images may not be displayed appropri-
ately without burst signals when camera
images are displayed in the black-and-
white mode depending on a monitor or
VCR model to be used. In such a case,
set the burst signal output to "ON".
