PREFACE
Panasonic presents highly advanced CCTV technology
that meets the demands of new and ever-changing
applications.
This high-performance combination colour camera is
utilized as a video surveillance device.
The camera incorporates Super-Dynamic
2 Digital
Signal Processor, pan-tilt mechanism, 22 zoom lens
and RS485 communication in a compact enclosure.
• High quality picture of 752 x 582 pixels
• Minimum illumination of 1 lx for colour and 0.06 lx
for black/white surveillance
• Super-Dynamic
2 extends the dynamic range up to
48 dB.
• Privacy zone feature enables users to veil unwanted
zones.
• Protocol adaptability to Panasonic's protocol
• Auto black/white mode enables the camera to
switch between C/L and B/W in response to input
lights.
• Reduction in minimum illuminance to 0.03 lx in the
black/white mode thanks to PIX SENS UP.
• Digital flip allows 180 ° tilting to trace objects pass-
ing under the camera.
Digital Flip Operation
-4-
A newly developed 1/4-inch CCD is employed for use
under extremely low light conditions: 0.06 lx for mono-
chrome and 1 lx for colour.
It also assures clear display of pictures in which bright
and dark objects coexist without mutual interference
thanks to Super-Dynamic
2 DSP. Setup menus allow
the camera to fulfill surveillance tasks by such means
as Motion Detector, Digital Flip, Patrol Learn and
Privacy Zones.
FEATURES
• A run of manual operations is memorized in the
patrol-learn mode for repetitive use in future.
• Built-in digital motion detector and alarm outputs
• Up to 64 preset positions
• 360 ° panning at a rotation speed of 300 °/s
• Sync selectable from among internal, line-lock and
VD2
• Automatic gain control circuit
• Image hold
• Digital noise reduction effect
• Setting change executable only by authorized per-
sonnel thanks to the password lock function
• Enhanced horizontal resolution by resolution setting
q Tilting down w The picture is
turned upside-
down instantly
around at 135
degrees of the tilt
angle.
e Tilting down
To Next Page
