Unit Number
Switch 1, an 8-bit DIP switch, specifies the unit number or restores the factory
default settings when using the Panasonic protocol.
When the switch position corresponding to the unit number 1 - 96* is selected,
setting should be made on the RS485 SET UP menu (see page 41).
1234
ON
5678
8-bit DIP SW
For Panasonic’s Protocol
