PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix
31
10. SET PINK NOISE TO LS
Select the Pink Noise generator output to Left
Surround. (Time Delay switch position “D”).
11. ADJUST SP23 LS INPUT LEVEL
Adjust the Left Input trimmer on the SP23 so
that the two green LEDs for the left channel
are equally illuminated.
12. COARSE SET LS SPL LEVEL TO
82dBC
Adjust the Left Surround Output trimmer on
the SP23 for approximately 82dBC in the
auditorium.
13. EQUALISE LEFT SURROUND
CHANNEL
Remove the Left/Right Equaliser card from the
SP23 and connect it via the extender card and
cable. Adjust the left equaliser controls for a
frequency response in accordance with the
standard ISO surround channel response
curve.
14. SET LS SPL LEVEL TO 82dBC
Re-adjust the Left Surround Output trimmer on
the SP23 for 82dBC in the auditorium.
15. SET PINK NOISE TO RIGHT
SURROUND
Select the Pink Noise generator output to
Right Surround. (Time Delay switch position
“E”).
16. ADJUST SP23 RIGHT SURROUND
INPUT LEVEL
Adjust the Right Input trimmer on the SP23 so
that the two green LEDs for the right channel
are equally illuminated.
17. COARSE SET RIGHT SURROUND
SPL LEVEL TO 82dBC
Adjust the Right Surround Output trimmer on
the SP23 for approximately 82dBC in the
auditorium.
18. EQUALISE RIGHT SURROUND
CHANNEL
Adjust the right equaliser controls for a
frequency response in accordance with the
standard ISO surround channel response
curve.
19. SET RIGHT SURROUND SPL LEVEL
TO 82dBC
Re-adjust the Right Surround Output trimmer
on the SP23 for 82dBC in the auditorium.
20. SET PINK NOISE TO LEFT
SURROUND
Select the Pink Noise generator output to Left
Surround. (Time Delay switch position “D”).
