PANASTEREO SP23 – Alignment with SMART MOD VI – DSP Matrix
33
33. COARSE SET REAR LEFT
SURROUND SPL LEVEL to 82dBC
Adjust the Rear Left Surround Output trimmer
(CSL) for approximately 82dBC SPL in the
auditorium.
34. EQUALISE REAR LEFT SURROUND
CHANNEL
Remove the Rear Equaliser from the SP23
and connect it via the extender card and cable.
Adjust the left equaliser controls for a
frequency response in accordance with the
standard ISO surround channel response
curve.
35. SET REAR LEFT SURROUND SPL
LEVEL TO 79dBC
Adjust the Rear Left Surround Output trimmer
(CSL) on the SP23 for 79dBC in the
auditorium.
36. TURN OFF LEFT REAR AMPLIFIER
AND TURN ON RIGHT REAR
AMPLIFIER
Switch off or disconnect the rear left surround
amplifier and switch on or re-connect the rear
right surround amplifier.
37. SET PINK NOISE TO RIGHT
SURROUND
Select the Pink Noise generator output to
Right Surround. (Time Delay switch position
“E”).
38. COARSE SET RIGHT REAR
SURROUND SPL LEVEL to 82dBC
Adjust the Rear Right Surround Output
trimmer (CSR) for approximately 82dBC SPL
in the auditorium.
39. EQUALISE REAR RIGHT SURROUND
CHANNEL
Adjust the right equaliser controls for a
frequency response in accordance with the
standard ISO surround channel response
curve.
40. SET REAR RIGHT SURROUND SPL
LEVEL TO 79dBC
Replace the Rear Equaliser card and adjust
the Rear Right Surround Output trimmer
(CSR) on the SP23 for 79dBC in the
auditorium.
41. TURN OFF PINK NOISE
Select the appropriate time delay setting on
the MOD VI Matrix board which will turn off the
pink noise source.
42. TURN ON REAR LEFT AMPLIFIER
Switch on or re-connect the rear left surround
amplifier.
