Page 40 Issue 2 22/4/98 MPC2000D
17. Fast Scan Analogue Data
The Fast Scan Analogue 1,2 and 3 can have the following data assigned to them to be read back to the PCX:-
Address Data Represented. Address Data Represented.
0 Current in I1 27 Hardwire Command
1 Current in I2 32 Total run time
2 Current in I3 33 Total starts
3 Current in I0 34 Total trips
4 Voltage in VP1 35 Thermal capacity
5 Voltage in VP2 36 Trip fault number
6 Voltage in VP3 37 Logic status
7 Voltage in VL12 38 Pre trip I1
8 Voltage in VL23 39 Pre trip I2
9 Voltage in VL31 40 Pre trip I3
10 Drive Status 41 Pre trip I0
11 Trips 42 Pre trip VP1
12 Alarms 43 Pre trip VP2
13 Time to trip 44 Pre trip VP3
14 Time to start 45 Last start period
15 Average RMS current 46 Last start peak current
16 Motor load 47 Pre trip Power
17 Unbalance 48 Fault status
18 Alarm fault number 70 RTD4
19 Frequency 71 RTD5
20 Resistance(4) 86 Dip Switch
23 Phase Sequence 92 Average Power
24 Control Input 1 93 Power Factor
25 Control Input 2 94 Power VA
26 Control Input 3
18. Changes To The Manual.
From Issue 1.
Earth Fault Display lower range is noted. (Section 5.4.)
Accuracy of Power for small motors is noted. (Section 5.6.)
Fast Scan Update Time Added. (Section 9.1.)
This manual is applicable to relays with software version 17/4/98.
All information is subject to change without notice.
