Pando PLB-7160 - Sound-Absorbing Strip Installation

Screw into
1
Take away
2
1
2
Sound-absorbing strip
Top
Left
Right
SOUND-ABSORBING STRIP INSTALLATION
Remove the protection from the
sound-absorbing strip, then fix the
strip on the frame.
Take away the four screws form
the right and left side plates.
Remove the protection from the
sound-absorbing strips, then stick
the strips to the side plates, please
align to the hole postion.
Screw on the screws after all.
