Pandora DXL 1840L User Manual

2.4 GHz
Antenna
Antenna GSM
Engine
temperature
sensor
Base block bottom view
LED indicator
VALET button
micro-USB
micro-USB
WARNING! Before starting the installation of the
system, choose a car model in ALARMSTUDIO
(CAN-bus protocol)
WARNING! SIM card should only be inserted
while the system is not powered.
IT IS FORBIDDEN to install the system on a car
with normal voltage other than 12V.
For remote engine start
White
2
IMMO-KEY2 OUT
Black
3
IMMO-KEY1 OUT
IMMO-KEY1 IN
IMMO-KEY
Green
1
Do not shield built-in antennas
Tachometer
200 mA (–)
200 mA (–)
200 mA (–)
200 mA (–)
200 mA (–)
200 mA (–)
200 mA (–)
(+)
(+)
2A (+)
200 mA (–)
200 mA (–)
200 mA (–)
(–)
CH5 - Output to beeper
CH1/INP1 - Doors triggers
CH4/INP4 - To turn signals
to original
wiring
INP5 - Brake pedal input (fuel level control)
INP3 - Front hood/Trunk trigger
СH3 OUT - NO Blocking
INP2 - To ignition lock
CH11 - Siren
3А
Ground
CH2/INP6
CAN1
CAN1-H
CAN1-L
CAN2
CAN2-H
CAN2-L
X6
X1
X1
X2 X6
X6
X5
X5
X5
X3
X4
X4
X4
Blue
9
Brown/White
10
Orange/Black
11
Yellow/Black
12
Blue/Black
13
Yellow
14
Purple
15
Red
16
White
1
Red/Black
2
Orange/White
3
Yellow/White
4
Gray
5
Green
6
White/Blue
7
Black
8
8
7
6
5
4
3
2
1
16
15
14
13
12
11
10
9
+ 12V
CH10 - Starter
CH9 - Bypass
CH6 - NO Blocking
CH7 - АСС (brake pedal)*
* When CH6 is assigned as “NC Blocking”
** For remote start implementation with Start/Stop button
CH8 - Ignition (Start-stop button)**
Brown
Orange
Blue
(–)
(–)
(–) (+)
(–) (+)
(–)
(+)
Green
Yellow
Red
36
5 2
14
(-)
+12V
NC
*
COM
NO
85
86
30
87 87a
Green
Green/Red
Green/Black
