Panduit PANTHER LS8E User Manual

KEYBOARD FUNCTIONS
11
Basic Keyboard Functions
• POWER – Turn printer on or off
• SETUP – Access the Set Up menu
• F1 – Display function key menu
• DELETE – Erase characters and tools
• CLEAR – Clear the entire screen
• FEED – Feed labels
• – Turn the backlight on or off
• PRINT – Print labels
• COPIES – Print multiple copies
• SIZE – Select the text font size
• LENGTH – Set the length of continuous label media
• STYLE – Select the text font style
• ALIGN – Change the label justification
• LINE – Add vertical and horizontal lines to a label
• FRAME – Add a frame around a label
• PAGE – Move to another page
• FILE – Access the file manager
• INSERT – Insert a new tool
• EDIT – Edit an existing tool
• LABEL – Change the label mode
• CAPS – Turn caps lock on or off
• HOME – Move to home position on screen
• END – Move to end position on screen
• SHIFT – Access secondary functions on keypad
• SPACE – Add a space to a label
• ACCENT – Insert an international character
• ENTER – Move to the next line or accept menu changes
• ROTATE – Rotate the label to 0, 90, 180, or 270 degrees

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
