Panduit PANTHER LS8E User Manual

2
Section 1: Getting Started...........................................................3
Introduction and Safe Operation..................................................4-6
General Description .....................................................................7-8
Loading Batteries and Label Cassette............................................ 9
Keyboard Functions .................................................................10-11
Section 2: Working with the P
ANTHER™ LS8E......................... 12
Using the P
ANTHER™ LS8E ..........................................................13
Creating Labels
Creating Text ...............................................................14-15
Creating Serializations..................................................16-18
Creating Symbols..........................................................19-21
Creating Data Lists ............................................................22
Creating Bar Codes ......................................................23-24
Creating a Date or Time Stamp.........................................25
Creating Lines...............................................................26-27
Creating Frames ................................................................28
Using Pages.......................................................................29
Using Special Functions ....................................................30
Setting up the P
ANTHER™ LS8E and Using File Manager.......31-33
P
ANTHERLINK™.........................................................................34-48
Labeling Exercises...................................................................49-55
Application Based Label Wizard ..............................................56-58
Printer Cleaning Instructions....................................................59-60
Printer Troubleshooting............................................................61-62
Frequently Asked Questions....................................................63-64
Warranty Information …................................................................65
General Specifications .................................................................. 66

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
