8
© 2007 Wohler Technologies, Inc. and PANORAMAdtv ALL rights reserved
HDMon Series User Manual P/N 821676 Rev-A
Rear Panel Features
A
B
C
D
E
F
G
H
I
J
Please refer to Figure-2 on the following page to familiarize yourself with the rear panel features of the HDMon-90-1. The
following sections describe these features and are referenced, by letter, to Figure-2. Note that aside from differences in LCD
specifications for the differrent models, all HDMon monitors are identical in operation and features.
Ethernet Connector
Ethernet 10/100 Base T network connectivity is provided at this RJ45 connector. A standard network cable
attached between this connector provides communication to a Windows computer for remote panel control and
setup over a network using the Wohler NETMON application GUI. The unit may also be networked to compatible
dedicated remote control panels. Default network address is for DHCP assignment at boot. Network setup for
normal operation is accomplished through the Console application (see page 11). See page 30 for a connector
pinout.
Console Serial Connector
Terminal serial based connectivity is provided at this DB-9 connector. A cable attached between this connector
and a serial terminal interface allows for remote setup of a number of parameters using the integrated Console
application in the HDMon firmware. Instructions for setting up and using the Console is provided on page 10.
See page 30 for a connector pinout.
Tally and Remote Control Connector
This DB-9 connector provides optically isolated connectivity to a tally system or remote control over the units
functions. Configuration of the remote inputs may be performed through the Console or the Wohler NETMON Windows
application. Refer to the Remote Cfg Menu on page 13 in the Console Operation section for how to assign parameter
settings to these buttons. For Tally pinout diagram and interface specifications, see page 30.
Power Connector (AC Mains Power)
Attach the supplied IEC-320 power cord between this connector and mains power (100 - 240VAC nominal, 50/
60 Hz). The front panel Power LED (Item 1, page 6) will indicate operating power status.
HD/SD-SDI Input and Output Connectors and Lock Status LEDs
The two BNC connectors labeled IN (SDI 1 and SDI 2), accept either HD-SDI or SD-SDI video input signals. The
two BNC connectors labeled OUT (SDI 1 and SDI 2), output an equalized copy of the HD/SD-SDI signal entering
the associated input. Connectors are terminated at 75 Ohms. The Lock Status LEDs (SDI 1 and SDI 2) light
GREEN if the HD/SD-SDI input signal entering the associated input is valid and locked, but is UNLIT if there is
no signal detected or the signal is not valid.
Composite Video Input Connector (Vid.)
This BNC connector accepts CVBS video input signals.
S-Video Video Input Connector (Y/C)
This 4-Pin Mini-DIN connector accepts S-Video (Y/C) video input signals. See page 30 for a connector pinout.
PC-RGBHV Input Connector (XVGA)
This HD-15 connector accepts PC-RGBHV VGA video input signals. See page 30 for a connector pinout.
Y-Pb-Pr Component Input Connectors (R, G/Y, B)
These three BNC connectors accept Y-Pb-Pr Component video input signals.
Digital Video Input Connector (DVI-D)
This DVI-D connector accepts Digital Video input signals. See page 30 for a connector pinout.
Power Connector (External DC Power)
An external 12 to 24V DC power source may be attached to this 4-pin XLR male connector. The front panel
Power Indication LED (Item 1, page 6) will indicate operating power status. Pin-4 is the positive (+) lead and
Pin-1 the negative (-).
K
