Pantum P2500W Plus Series User Manual

51
8. Control Panel
8.1. Control Panel Overview for P2500 Series
The printer control panel layout includes 2 buttons and 2 multi-colored LED indicators as shown
below. The diagram on the left shows the control panel of the printer with USB+Wi-Fi interface,
while the one on the right displays the control panel of the printer with USB interface only:
Serial No.
Name
1
Multi-colored LED1 indicator
2
Multi-colored LED2 indicator
3
Wi-Fi search button
4
Cancel/Continue button
5
Information button
8.1.1. Functions of Buttons on the Control Panel
8.1.1.1. Operation Function of Wi-Fi Search Button
When there is no Wi-Fi connection,short press the launch Wi-Fi connection and simultaneously
openthe printer Bluetooth function,search the Wi-Fi Hotspot AP,and the access point AP cannot be
searched in 2 minutes,the search is stopped.
When there is no Wi-Fi connection,longpress automatically print "Mobile Device Wi-Fi Connection
Wizard"page.
If there is Wi-Fi connection while no Wi-Fi print job, press and hold this button to disconnect Wi-Fi
connection.
If there is Wi-Fi connection and Wi-Fi print job, wait until the job is completed and then press and
hold this button to disconnect the Wi-Fi connection.
Long press can cancel Wi-Fi during Wi-Fi connection.

Pantum P2500W Plus Series Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	15, 000 pages
Input Capacity	150 sheets
Output Capacity	100 sheets
Processor Speed	600 MHz
Memory	128 MB
Mobile Printing Capability	Yes (Pantum App)
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	22 ppm (A4)
Connectivity	Wi-Fi, USB 2.0
Media Sizes Supported	A4, A5, A6, Letter, Legal
Media Types Supported	Plain, Thick, Cardstock, Label, Envelope, Thin
Dimensions	337 x 220 x 178 mm
Power Consumption (Printing)	370 watts
Recommended Monthly Volume	2, 000 pages
Power Consumption (Sleep)	Less than 2W
