ParaBody 821 - Parts List

PARTS LIST
DESCRIPTION
ROLLER PAD SUPPORT
BASE TUBE
HIP PAD SUPPORT
CROSS BRACE
FRONT UPRIGHT
REAR UPRIGHT
PAD ASSEMBLY
ROLLER PAD
3/8 X 1” BOLT
3/8 X 3” BOLT
1/2 X 3” BOLT
3/8” LOCK NUT
KEY
13
14
15
16
17
18
19
20
21
22
23
PART #
3102601
3102501
3102502
3102801
6467001
6692601
3105401
3103102
6590801
6412001
6405201
DESCRIPTION
3/8” LOCK WASHER
3/8” WASHER
1/2” WASHER
1/2” LOCK NUT
2” SQ. COVER CAP
3 X 2” END CAP
STARLOCK COLLAR
1 X 8” GRIP
3 X 2” INSERT GUIDE
3/8” SPRING PIN ASSEMBLY
2” SQ. END CAP
QTY
4
10
8
8
4
1
2
2
2
1
2
PART #
6588702
6511708
6588308
6588508
6588908
6589108
6589321
6194601
3102909
3102904
3102910
3102802
KEY
1
2
3
4
5
6
7
8
9
10
11
12
QTY
1
2
1
1
1
1
2
2
5
2
8
3
FIGURE 1
5
STEP 1:
• SECURELY assemble the CROSS BRACE (4) to the FRONT and REAR UPRIGHTS (5 & 6) using four 1/2 X
3” BOLTS (11), four 1/2” WASHERS (15) and four 1/2” LOCK NUTS (16) as shown in FIGURE 1.
15
6
16
4
5
1/2 X 3”11
