STEP 2:
Install two Nut Caps (43) onto Lock Nuts (15). Slide one Protective Cover (37) on to each side of
the base as shown, and pull down on the Protective Covers (37) until the bottom of the covers are
slightly lower than the Folding Arms (8). Use the velcro straps on the bottom of the Protective
Covers (37) to secure the covers to the Folding Arms (8). When the covers are assembled
correctly, the Folding Arms (8) should be fully covered by the Protective Covers (37) with the logo
on the side.
9
