Esprit 728 Ultra & 738 Ultra - 11 - Programming Guide
Table 10: Zone Definition
Do not use the Intellizone feature and an entry delay for the same zone, otherwise an alarm may occur as a user tries to
disarm the system. Zones that are not selected at addresses 100 to 112 (728 Ultra) or 114 (738 Ultra) become “Delay 1” zones.
Key Access Programming
Programs features quickly, without entering addresses or sections numbers. To activate Key Access Programming, press [ENTER]
followed by the Installer code, Master code or User code 1 (code required depends on the desired feature; see below). Press the key
corresponding to the desired feature. Press [
ENTER] or [CLEAR] to exit. When communicating with Espload, it is impossible to enter
programming mode.
Address
KEY SELECT:
[1] [2] [3] [4] [5] [6] [7] [8] [9] [0] [STAY][FORCE]
/[
AWAY]
[1] [2] [3] [4] [5] [6]
Zone: 1234567891011 12 13 14 15 16 17 18
092:
Intellizone =
ON
092: NNNNNNNNNN N N 094: NN NNNN
Zone: 1234567891011 12 13 14 15 16 17 18
096:
Silent = ON 096: NNNNNNNNNN N N 098: NN NNNN
Zone: 1 2 3* 4567891011 12 13 14 15 16 17 18
100:
24Hr./Fire = ON 100: NNNNNNNNNN N N 102: NN NNNN
Keypad zones
cannot be set as
24Hr zones.
* When zone 3 is defined as 24Hr, it becomes a 4-wire smoke detector fire zone (2-wire smoke detector support must be
disabled, address 086 key [
BYP] = OFF).
If using 2-wire smoke detectors and ATZ is enabled, zone 3 can be defined as 24Hr (728 Ultra only).
Zone: 1234567891011 12 13 14 15 16 17 18
104:
Instant = ON 104: NNNNNNNNNN N N 106: NN NNNN
Zone: 1234567891011 12 13 14 15 16 17 18
108:
Follow = ON 108: NNNNNNNNNN N N 110: NN NNNN
Zone: 1234567891011 12 13 14 15 16 17 18
112:
Delay 2 = ON 112: NNNNNNNNNN N N 114: NN NNNN
SYSTEM A / STAY
(if ON, zone is armed on Stay or “System A” arming)
Zone: 1234567891011 12 13 14 15 16 17 18
116:
116: NNNNNNNNNN N N 118: NN NNNN
SYSTEM B
(if ON, zone is armed in “System B” arming)
Zone: 1234567891011 12 13 14 15 16 17 18
120:
120: NNNNNNNNNN N N 122: NN NNNN
Zone: 1234567891011 12 13 14 15 16 17 18
124:
Bypass = ON 124: NNNNNNNNNN N N 126: NN NNNN
Fire zones cannot be bypassed.
Table 11: Key Access Programming
Key Feature
Codes that can access feature
[8]
Installer Test Mode
Installer Code Only
In Installer Test mode, a confirmation beep (intermittent) indicates that the test
mode is enabled. A rejection beep indicates that the test mode is disabled. The
bell will squawk during walk testing to indicate opened, functional zones.
[9]
“Auto Arming” Time Program
Installer Code, Master Code or User Code 1
Key [9] flashes. Enter 2-digit hour (00 to 23) and 2-digit minutes (00 to 59).
[MEM]
Panel Time Programming
Installer Code, Master Code or User Code 1
[MEM] key flashes. Enter 2-digit hour (00 to 23) and 2-digit minutes (00 to 59).
[BYP]
Test Report
Installer Code, Master Code or User Code 1
Reporting is enabled at address 086, keys [STAY] and [AWAY]/[FORCE] (see
page 10). A value must be entered at address 512 (page 7) and both telephone
and account numbers must be programmed.
[TRBL]
Call Espload Via Telephone
Installer Code, Master Code or User Code 1
Panel identifier and PC password (addresses 004 to 007 on page 3) and
computer telephone number (addresses 008 to 015 on page 3) must be
programmed.
[AWAY]
Answer Espload
Installer Code, Master Code or User Code 1
This feature is available when using the ADP-1 adapter. In Espload, “blind dial” must
be activated in the “modem setup” section and panel phone number programmed.
[STAY]
Cancel Communication Attempts
Until next reportable event.
Master Code/User Code 1 only cancel calls to Espload
The Installer Code can cancel all communications
