NV37M-EI00 07/2021 PARADOX.COM
Beam Pattern
PET Mode
SHARP Mode
Top View
LED Display
Technical Specifications
Feature LED Status Indicator
Tamper open Green: ON for 0.3 seconds every 30
seconds
PIR sensitivity level setting Green: Flashes 1-3 times according
to the selected level
Alarm detection Red: ON for 2 seconds
Booting/Tamper close Green/Red alternating flashes for 30
seconds
Anti-mask detection Flashing Orange:
Pre-mask situation is detected.
Orange LED flashes ON/OFF 3
times.
Solid Orange:
Real mask is detected (can take
between 20 -150 seconds after the
pre-mask situation).
Orange LED will remain solid “ON”
while mask is present.
SIDE VIEW:
0.5m
1m
1.5m
5m1m 2m 3m 4m 6m 7m 8m 9m 10m
(32.8ft)
2m
(6.5ft)
0m
0m
Specification Description
Infrared sensor type 2 Dual elements
Detection range • PET Immunity mode: 7.5m x 2m
(25 x 7 ft)
• Sharp mode: 10 x 2m (33 x 7 ft)
Super Pet Immunity Pet size approximately 50cm
Anti- mask Active IR detection for blocking items 30cm
and sprayed liquid
Input voltage 9 to 16 VDC
Current consumption Typical: 15mA
Maximum: 19.2mA
Compatibility EVO, Spectra and Magellan systems
Outdoor protection IP54
Operation
temperature
-40°c to +70°c
Relative humidity 95% non-condensing
Dimensions 12.3 x 6.1 x 4.3 cm (4.8 x 2.4 x 1.7 in.)
Certifications CE, EN50131-2-2 Grade 3, Class IVA
Certification Body: Applica Test &
Certification
Note: EN performance tests were
conducted on sensitivity level 3 (high).
Weight 100g / 0.2 lb
Warranty
For complete warranty information on this product, please refer to the
Limited Warranty Statement found on the website: www.paradox.com/
terms or contact your local distributor. Specifications may change without
prior notice.
Patents
US, Canadian and international patents may apply. Paradox
is a trademark or registered trademark of Paradox Security
Systems (Bahamas) Ltd.
