P10 INSTALLATION INSTRUCTIONS
Gas supply routing.
Check the gas run to assess that the gas supply is capable of providing the required amount of
gas and is in accordance with the rules in force.
Soft copper pipe can be used to install the appliance. Soldered joints can be used only
externally of the appliance.
The appliance is supplied with a factory fitted isolation device to allow for an 8mm copper
connection. No further isolation point is required.
The new gas line must be purged of any debris, prior to final connection to the appliance.
Gas inlet isolation device is located on bottom left hand side of the fire box, the gas supply entry
point is positioned at the rear bottom on left hand side. With the appliance fixing kit is a 35mm
round seal (Please see fig 3), this should be cut and fitted over the 8mm copper at the point the
gas supply entry into the appliance assembly. The burner assembly will need to be removed by
removing the two retaining screws. With the screws removed lift the burner assembly up on the
left hand side and remove from the burner carrier. (Special care must be taken not to damage
or dislodge the burner silencer located on the right hand side.
The gas inlet isolation device must be angled to allow access to the grub screw and gas test
nipple.
