P10 MAINTENANCE INSTRUCTIONS
Replacement of the Burner Assembly
Remove the glass panel as described on page 6 of the users instruction section.
Remove the Loose shapes.
Undo the two fixing screws retaining the burner assembly with the carrier.
Lift the burner clear of the silencer and injector tip.
Clean or replace the burner assembly.
Re-assemble in reverse order.
Replacement of the Electronic Control Unit (ECU)
Remove the glass panel as described on page 6 of the users instruction section.
Remove the Loose shapes.
Repeat the process above (replacement of the burner assembly).
Undo the two M3 nuts retaining the ECU unit and remove the connection bracket.
Unplug the connection from the ECU board.
Re-assemble in reverse order.
