The height from the floor to the mattress base
surface can be adjusted electrically.
The angle of the back and knee section bases and the bed height and inclination angle
(Trendelenburg and Reverse Trendelenburg) can be electrically adjusted with no increments.
■The angle of the leg section base can be manually adjusted in two levels.
The angle of the knee section base can be
adjusted electrically from an angle of 0⁰ to 25⁰.
When performing a position operation, check that the patient’s head, arms, feet, or other body
parts have not entered the gap of the side-rails, or the space between the back section base and
the frame; There is a risk of getting caught, resulting in injury.
●When performing the height adjustment or inclination angle adjustment with the side-rail
lowered, do not place legs under the side-rail. There is a risk of getting caught, resulting
in injury.
Do not allow the patient to get into or out of the bed while the bed is
in the chair position. There is a risk of injury caused by the patient
falling down.
●Setting the bed to the chair position must only be performed under
the observation of a physician or a nurse.
The angle of the back section base can be
adjusted electrically from an angle of 0⁰ to 70⁰.
