15. Extension frame function
When using the extension frame function, make sure to use a suitable extension mattress. There is
a risk that a part of the body may get caught in a gap between the bed and the extension frame,
resulting in injury.
●Do not place your hand, foot or knee on the edge of the extension mattress. Since there is no
support, you may lose a balance and there is a risk of injury caused by a fall.
●Do not use the extension frame function for patients who cannot maintain their posture
independently. There is a risk of injury caused by a patient falling off the bed.
The bed can be extended 10cm for tall patients by pulling out the extension frame and
adding an extension mattress.
[Pulling out the extension frame]
①Loosen the knobs on both side of the bed under
the leg section base.
②Pull the extension frame out until it stops.
③Tighten the knobs and lightly push the extension
frame to make sure that it is properly locked.
④Place the extension mattress on the extension frame.
[Storing the extension frame]
①Remove the extension mattress.
②Loosen the knobs on both side of the bed under
the leg section base.
③Push the extension frame in until it stops.
④Tighten the knobs and lightly pull the extension
frame to make sure that it is properly locked.
When loosening knob, do not rotate it
too much. The knob may come off, and
may be lost.
Knob
Leg section base
Tighten
Loosen
Extension mattress
When the extension frame is used
When the extension frame is retracted
Extension frame
