36
15. X-ray cassette tray
■
Setting a Cassette.
Set a cassette while the back section base is in holizontal status.
Lock position
Unlock position
Lock lever
Grip
Cassette tray
Lock lever
①
Detach the headboard.
②Pull the lock lever to unlock it.
③
Hold the grip and pull the cassette
tray all the way out.
④Set the cassette stopper to the appropriate
position. The cassette stopper can be
adjusted in 5 levels.
⑤Set a cassette in the cassette tray.
⑥Hold the grip and slowly insert the cassette
tray all the way to the rear.
⑦Push the lock lever until it locks into place.
Cassette stopper
Cassette stopper
Cassette
OPERATION PROCEDURES
6
