Park Tool PCS-10.3 - Page 3

7
6
22
18
5
18
7
15
4
8
41
37
40
38
47
55
56
42
52
48
43
45
45
44
46
45
50
49
53
51
39
54
Ref. # Part # Description Qty.
37 2834 Clevis Pin C-Clip 1
38 467-1 Washer 4
39 2860 Jaw Cover (Set) 1
40 2844 Clamp Saddle 1
41 2823-10 Rotating Jaw 1
42 2826 -10 Moveable Jaw 1
43 2831 Hex Barrel-Threaded 1
44 2832 Hex Barrel-Unthreaded 1
45 2830 Hex Bushing 4
46 2829 Hex Bolt 4
47 1806 Spring 1
48 2833L Clevis Pin 1
49 1808X Step Bushing 1
50 1809 Nylon Washer 1
51 1810 Clamp Screw 1
52 1964 Handle Screw 1
53 1965 Handle Screw Cap 1
54 1966A Handle Assembly 1
55 1967 Handle Knob 1
56 1968 Handle Knob Screw 1
PCS-10.3 PART NUMBERS
