Parker Hiross Hyperfilter User Manual

33HFN005-370
Fig.1 Wall mounting kit
1
2
1
2
3
INSTRUCTIONS:
Attach each filter support (2) to thehead (3) by use of the s elf---
tapping screws (1). Then mount the filter onto the wall.
Fig.2 Connection to compressed air piping
IN
OUT
air flow
direction
arrows
Fig.3 Mounting in series
wolfriawolfria
Tab. 1 - Operational characteristics
GRADE WORKING RANGE
FILTER ELEMENT PRESSURE DROP (barg)
new
nominal
new
oil saturated
recommended
maximum
D 1.5 - 65 °C 0.07 0.14 0.35
Q 1.5 - 65 °C 0.07 0.14 0.35
P 1.5 - 65 °C 0.07 0.14 0.35
S 1.5 - 65 °C 0.10 0.20 0.35
C 1.5 - 30 °C 0.07 N.A
Substitute element
before oil saturation
(~1000h at 25°C).
