Parker Airtek TWB1500 User Manual

TWP/TWB200 – TWP/TWB9000
65
Blower Purge Spare Parts List (Flow schematic drawing# FS11686)
MODEL TWB200 TWB300 TWB400 TWB500 TWB600 TWB800
DESICCANT PART ID PART NUMBER
DESICCANT 25LB BAGS (QTY) AV1, AV2 PDA-1/8-25 (12) PDA-1/8-25 (20) PDA-1/8-25 (24) PDA-1/8-25 (30) PDA-1/8-25 (36) PDA-1/8-25 (48)
FILTER ELEMENTS
COALESCER ELEMENT (QTY) PF1, PF2 JF0320G-6CK (1) JF0320G-6CK (1) JF0430H-6CK (1) JF0650J-6CK (1) JF0650J-6CK (1) JF0900K-6CK (1)
PARTICULATE ELEMENT (QTY) AF1, AF2 JE-FC0350-HT (1) JE-FC0350-HT (1) JE-FC0450-HT (1) JE-FC0625-HT (1) JE-FC0625-HT (1) JE-FC0800-HT (1)
CONTROL AIR FILTER ELEMENT (QTY) CF1 TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1)
BLOWER INTAKE ELEMENT BF1 TP1415-E TP1415-E TP1415-E TP1420-E TP1420-E TP1420-E
REPAIR KITS
INLET VALVE REPAIR KIT PV2, PV3 TP7615-P1-RK TP7615-P1-RK TP7620-P1-RK TP7620-P1-RK TP7620-P1-RK TP7620-P1-RK
EXHAUST VALVE REPAIR KIT PV1, PV4 TP7510-P1-RK TP7510-P1-RK TP7515-P1-RK TP7520-P1-RK TP7520-P1-RK TP7520-P1-RK
OUTLET CHK VALVE REPAIR KIT CV1 TP7415-SDX-RK TP7415-SDX-RK TP7420-SDX-RK TP7420-SDX-RK TP7420-SDX-RK TP7420-SDX-RK
PURGE CHK VALVE REPAIR KIT CV3, CV4, CV5 TP7415-AB-RK TP7415-AB-RK TP7415-AB-RK TP7420-AB-RK TP7420-AB-RK TP7420-AB-RK
REPLACEMENT PARTS
INLET VALVE PV2, PV3 TP7615-P1 TP7615-P1 TP7620-P1 TP7620-P1 TP7620-P1 TP7620-P1
EXHAUST VALVE P1, PV4 TP7510-P1 TP7510-P1 TP7515-P1 TP7520-P1 TP7520-P1 TP7520-P1
OUTLET CHECK VALVE CV1 TP7415-SDX TP7415-SDX TP7420-SDX TP7420-SDX TP7420-SDX TP7420-SDX
PURGE CHECK VALVE CV3, CV4, CV5 TP7415-AB TP7415-AB TP7415-AB TP7420-AB TP7420-AB TP7420-AB
2% COOLING VALVE S6 TP8003 TP8003 TP8003 TP8003 TP8003 TP8003
REPRESSURIZATION VALVE S5 TP8003 TP8003 TP8003 TP8003 TP8005 TP8005
CONTROL SOLENOID VALVE S1, S2B, S3B, S4 TP8101-1D TP8101-1D TP8101-1D TP8101-1D TP8101-1D TP8101-1D
DRAIN VALVE S10, S11 TP8002 TP8002 TP8002 TP8002 TP8002 TP8002
MUFFLER, EXHAUST ES1, ES2 TP4215-1 TP4215-1 TP4215-1 TP4220-1 TP4220-1 TP4220-1
FILTER, CONTROL AIR CF1 TP2201-P TP2201-P TP2201-P TP2201-P TP2201-P TP2201-P
SAFETY RELIEF VALVE PSV1, PSV2 TP7105 TP7105 TP7105 TP7105 TP7105 TP7105
PRESSURE GAUGE PI1, PI2, PI3 LP1020 LP1020 LP1020 LP1020 LP1020 LP1020
ORIFICE 2% COOLING RO1 TP4312 TP4318 TP4318 TP4322 TP4322 TP4325
BACKUP PURGE ORIFICE RO2 TP4118 TP4122 TP4125 TP4128 TP4131 TP4137
FILTER DP GAUGE DPI1, DPI2 2198HX 2198HX 2198HX 2198HX 2198HX 2198HX
THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD
HEATER HT1 TP3606 TP3606 TP3609 TP3612 TP3612 TP3615
BLOWER BL1 TP1707-4 TP1715 TP1715 TP1730-3 TP1730-3 TP1752
PRESSURE TRANSDUCER PT1, PT2, PT3, PT4 TP2451 TP2451 TP2451 TP2451 TP2451 TP2451
FLOW SWITCH FS1 DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB
HEATER CONTACTOR C1, C2 ES5050 ES5050 ES5050 ES5050 ES5050 ES5050
BLOWER CONTACTOR MS1 ES5003-5AF ES5003-5AF ES5003-5AF ES5003-5AF ES5003-5AF ES5003-5AF
STARTER OVERLOAD OL ES5001-TF-1.7 ES5001-TF-3.1 ES5001-TF-4.2 ES5001-TF-5.7 ES5001-TF-5.7 ES5001-TF-10.0
HEATER FUSE EF1500 EF1500 EF1500 EF2000 EF2000 EF2500
BLOWER FUSE EF3002.5 EF3005 EF3006 EF3008 EF3008 EF3015
PLC PLC1 TP2681-PLC-B800 TP2681-PLC-B800 TP2681-PLC-B800 TP2681-PLC-B800 TP2681-PLC-B800 TP2681-PLC-B800
HMI DISPLAY HMI TP2681-HMI-B800 TP2681-HMI-B800 TP2681-HMI-B800 TP2681-HMI-B800 TP2681-HMI-B800 TP2681-HMI-B800
FUSE, 1 AMP F1, F3 EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD
FUSE, 3 AMP F2 EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD
MEMORY CARD TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM
DEWPOINT PROBE AE1 TP2190-1 TP2190-1 TP2190-1 TP2190-1 TP2190-1 TP2190-1
MODELS WITH NEMA 4
NEMA 4 THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2083-N4 TP2083-N4 TP2083-N4 TP2083-N4 TP2083-N4 TP2083-N4
MODELS WITH OUTDOOR PACKAGE
BLOWER INTAKE ELEMENT BF1
MODELS WITH INSTRUMENTATION OPTION
PRESSURE GAUGE PI4, P5 LP1020 LP1020 LP1020 LP1020 LP1020 LP1020
TEMPERATURE GAUGE TG1, TG2 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25
