Parkray ASPECT 4/4 COMPACT - Page 10

10
Upper and Lower Rear Bricks
Baffle/Throat Plate
Stove Assembly
Flue Collar
Push up and (A) drop one edge
downward into the bottom of the
stove and pull outwards (B).
Place the flue collar gaskets on the outlet to be used.
Push the upper brick upwards (A).
Then pull the bottom edge of the
rear brick forward (B) and lift the
brick out of the stove. Repeat with
the lower brick.
Top and rear outlet
