Parkside Performance PSBSAP 20-Li B2 User Manual

PSBSAP 20-Li B2
■ 8
│
GB
│
IE
Inserting/removing the battery pack
Inserting the battery pack
♦ Set the rotation direction switch7 to the middle
position (lock). Push the battery packe into
the handle until it clicks into place.
Removing the battery pack
♦ Press the release buttonr and remove the
battery packe.
Checking the battery charge level
♦ Press the battery charge level buttonu to
check the status of the battery. The status/
remaining charge will be shown on the battery
display LEDz as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Additional handle
NOTE
►
For safety reasons, you should never use
this tool without the additional handle1
attached.
♦ Loosen the strap on the additional handle1
by turning it clockwise.
♦ Slide the mounting ring for the additional
handle4 over the chuckw.
♦ Turn the additional handle1 to the required
position.
♦ Afterwards, twist the additional handle1
anticlockwise again to tighten it.
Depth stop
♦ Undo the screw on the depth stop 5.
♦ Fit the depth stop2 into the additional
handle1.
♦ Make sure that the teeth on the depth stop3
point upwards and downwards.
♦ Pull the depth stop2 out until the distance
between the tip of the drill and the tip of the
depth stop corresponds with the required
drilling depth.
♦ Tighten the screw on the depth stop 5 to
lock the depth stop 2 into place.
Changing tools
Your cordless impact drill driver has a fully auto-
matic spindle lock
.
When the motor is stopped, the power train is
locked so that the chuckw can be opened by
turning
. After you have attached the desired
tool and tightened it by turning the chuck , you
can continue working. The spindle lock is released
automatically when the motor is started (by pressing
the ON/OFF switch8).
Torque selection/selecting the
operating mode
You can set the torque using the torque selection
ringq or by choosing between the drill setting
and the hammer drill setting
.
♦ Select a low level for small screws or soft
materials.
♦ Select a high level for large screws, hard
materials or removing screws.
♦ Select the drill setting for drilling work by adjusting
the torque selection ring to the position
.
♦ Select the hammer drill setting for hammer drilling
work by adjusting the torque selection ring to
the position
.

Parkside Performance PSBSAP 20-Li B2 Specifications

General

Battery Voltage	20 V
Battery Type	Li-Ion
Battery Capacity	2.0 Ah
Chuck Size	13 mm
Max Torque	60 Nm
No-load Speed	0-500 / 0-2000 rpm
Drilling Diameter in Steel	13 mm
