PSBSAP 20-Li B2
GB
│
IE
│
3 ■
Package contents
1 cordless impact drill
2 battery packs
1 high-speed charger
1 additional handle
1 cutter knife (incl. 8 spare blades)
1 ratchet screwdriver (1/4”)
1 screwdriver (1/4”)
72 bits
2 bit holders
1 measuring tape
6 wood drill bits
6 metal drill bits
6 concrete drill bits
1 depth stop
1 carrying case
1 set of operating instructions
Technical data
Cordless impact drill PSBSAP 20-Li B2
Rated voltage 20 V (DC)
Gears 2-speed gearbox
Rated idle speed 1st gear: n
0
0–400 rpm
2nd gear: n
0
0–2000 rpm
Stroke frequency 1st gear: n
0
0–7200 rpm
2nd gear: n
0
0–36000 rpm
Max. torque 80 Nm
Torque levels 1–21 + 1 drill setting/
+ 1 hammer setting
Chuck capacity
max. Ø 13 mm
Max. drill diameter 65 mm for wood
16 mm concrete
(without stones)
13 mm for steel
Battery PAP 20 B1
Type LITHIUM ION
Rated voltage 20 V
(DC)
Capacity 2 Ah
Cells 5
High-speed charger PLG 20 C2
INPUT
Rated voltage 230–240 V ∼, 50 Hz
(AC)
Rated power
consumption 85 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 3.5 A
Charging time approx. 45 min
Protection class II /
(double insulation)
Noise emission value
Noise measurement value determined in accordance
with EN 62841. The A-rated noise level of the power
tool is typically:
Sound pressure level L
PA
= 89 dB (A)
Uncertainty K K
PA
= 5 dB
Sound power level L
WA
= 100 dB (A)
Uncertainty K K
WA
= 5 dB
Vibration emission value
Total vibration values (vector total of three direc-
tions) determined in accordance with EN 62841:
Impact drilling in concrete a
H,ID
= 6.1 m/s
2
Uncertainty K = 1.5 m/s
2
Wear ear muffs!
NOTE
► The vibration emission values and the noise
emission values given in these instructions
have been measured in accordance with
a standardised test procedure and can be
used for comparison of the power tool with
another tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.
