Operation
Additional handle
NOTE
► For safety reasons, you should only use this
appliance with the additional handle
attached.
♦ The gripping position of the additional handle
can be varied.
Turn the wing screw anticlockwise and pull
the additional handle off the appliance a
little way.
♦ Turn the additional handle
to the desired
position.
♦ Now, slide the locking positions on the addi-
tional handle
over the two locking pins on
the spindle of the appliance.
♦ Retighten the wing screw
afterwards by
turning it in a clockwise direction.
NOTE
► Turn the additional handle
into the various
locking positions depending on your working
position. Undo and lock the additional han-
dle as described previously.
Depth stop
♦ Undo the wing screw .
♦ Insert the depth stop
into the additional
handle .
♦ Ensure that the toothing on the depth stop
is
facing downwards.
♦ Pull the depth stop
out until the distance
between the tip of the drill and the tip of the
depth stop with the required drilling depth.
♦ Retighten the wing screw
afterwards.
Fitting/removing a tool
WARNING!
► Switch the appliance off and remove the
power plug before starting any work on the
appliance.
Fitting a tool:
♦ Before fitting a tool, grease the tool holder
lightly with machine grease.
♦ To insert, pull the locking collar backwards
and insert the tool.
♦ Release the locking collar
. This locks the
tool holder . Check that the tool is properly
locked by pulling it. The system has radial play
because of the design.
Removing a tool:
♦ To release the tool, pull the locking collar
backwards.
Quick-release chuck for round shaft
drill bits
WARNING!
► Do not use the quick-release chuck
for
hammer drilling or chiselling!
♦ Set the function selector switch to the drill
symbol
.
Inserting the quick-release chuck for round
shaft drill bits:
♦ To insert the quick-release chuck
(see also
fig. A) pull the locking collar backwards.
Insert the quick-release chuck .
♦ Release the locking collar . This locks the
tool holder . Check that the tool is properly
locked by pulling it.
Removing the quick-release chuck for round
shaft drill bits:
♦ To remove the quick-release chuck
, pull the
locking collar backwards and remove the
quick-release chuck .
