Parkside PFS 450 A1 User Manual

PFS 450 A1
■ 6
│
GB
│
IE
Setting up
Assembly/disassembly
♦ Move the ▸ mark on the spray unit
to the
mark on the motor unit . Now, turn the spray
unit
until the ▸ mark on the spray unit
locks into the
mark on the motor unit
♦ Unlock the lock
5a
. Turn the ▸ mark on the
spray unit
to the
mark on the motor
unit to separate the two units.
Choosing/changing the nozzle
Nozzle Use
1.5 mm nozzle
Low viscosity
1.8 mm nozzle
Water-based paints
2.2 mm nozzle
High viscosity
2.6 mm nozzle
Oil-based paints
♦ Undo the union nut
completely and remove
it from the spray unit .
♦ Fit the desired nozzle
onto the nozzle
head .
♦ Screw the union nut
back onto the spray
unit .
Adding spray material
♦ Unscrew the paint cup from the spray
unit .
♦ To work on a horizontal object, place the riser
pipe
in front, facing the nozzle head .
To work overhead, place the riser pipe in the
back, facing the motor unit .
♦ Fill the paint cup
with the spray material
and screw it firmly onto the spray unit .
Switching the appliance on/off
Working methods
♦ Hold the spray gun at a constant distance from
the object. The ideal spraying distance is
approx. 15 cm.
♦ Work out the best settings by carrying out a test.
♦ Do not switch the appliance on/off over the
spray surface. Rather, start/end the spraying
process approx. 10 cm from the spray surface.
Switching on
♦ Insert the plug into a mains power socket.
♦ To switch the appliance on, pull the trigger
and keep it pulled.
Switching off
♦ To stop spraying, simply release the trigger
.
♦ When you are finished working, disconnect the
plug from the mains power supply.
Selecting a spray profile
Setting the spray volume
♦ Turn the spray volume adjusting wheel
to
the desired position:
(–) = minimum spray volume
(+) = maximum spray volume
NOTE
► We recommend starting at the minimum
setting.
Selecting a jet type
♦ Undo the union nut .
♦ Turn the protruding parts of the nozzle head
so that they point to the desired symbol on the
spray unit .
The appliance has the following settings:
▯ round jet
vertical flat jet
horizontal flat jet
♦ Re-tighten the union nut
.
