9
IEGB
connecting the rapid-action wa-
ter supply connector to the wa-
ter connection with sieve insert
(8).
• Connect to the spray gun (10)
by inserting and screwing in the
jet tube (11).
• If the jet tube (11) is tted, con-
nect either the adjustable fan
nozzle (12), high-pressure jet
(13) or cleaning agent container
to the nozzle (14) by screwing
together with the jet tube (11).
With using the cleaning agent
container with the nozzle (
14), pour only cleaning agent
into the container. It is sucked in
automatically.
The width of the jet can be increased by
turning the end of the nozzle to the left. To
reduce the width of the jet, turn the end of
the nozzle to the right.
Mains connection
The pressure washer you have acquired
is already tted with a mains plug. The
pressure washer must only be connected
to an earthed socket 230 V ~ 50Hz.
Only operate the pressure washer
after all the above points have
been observed.
• Ensure that the pressure washer is
turned off by its ON / OFF switch (
5).
• Insert the mains plug into the mains
socket
Scope of Delivery
Unpack the pressure washer and verify
the contents:
- Pressure washer
- Chassis
- Gun
- High-pressure hose
- Jet lance
- High-pressure nozzle
- Adjustable at-jet nozzle
- Cleaning agent container with nozzle
- Nozzle cleaning pin
Start-up
In keeping with current regulations
a pressure washer must never be
operated off the drinking water
mains supply without a controlla-
ble backow preventer. A suitable
backow preventer in conformity
with EN 12729 type BA must be
used.
Water that has passed through a backow
preventer is classied as undrinkable.
A backow preventer is available
from specialist retailers.
Setting up
• Screw the equipment side of the
high-pressure hose connection
(2) to the high-pressure hose
connection (3) on the equip-
ment.
• Screw the gun side of the high-
pressure hose connection (1) to
the spray gun (10)
• Establish the water supply by
To Next Page
