• Do not pull the plug from the socket by
the cable. Protect the cable from heat,
oil and sharp edges.
• Do not carry or x the equipment by
the cable.
• Use only extension cables that are pro-
tected from spray water and designed
for outdoor use. Always fully unroll a
cable drum before use. Check the ca-
ble for damage.
• Before any work on the equipment,
during work breaks and in the case
of non-use, remove the plug from the
socket.
• The cross-section of the power supply
cable must not be less than 2 x 2,5
mm².
• Wear sturdy footwear to protect
against electric shock.
• Warning ! Inadequate extension
cords can be dangerous. If an exten-
sion cord is used, it shall be suitable
for outdoor use, and the connection
has to be kept dry and off the ground.
It is recommended that this is accom-
plished by means of a cord reel which
keeps the socket at least 60 mm above
the ground.
Start-up
In keeping with current regulations
a pressure washer must never be
operated off the drinking water
mains supply without a controlla-
ble backow preventer. A suitable
backow preventer in conformity
with EN 12729 type BA must be
used.
Water that has passed through a backow
preventer is classied as undrinkable.
A backow preventer is available
from specialist retailers.
• Employ an ordinary garden hose for
the water intake and ensure sufcient
length.
Setting up
B
• Screw the equipment side of the
high-pressure hose connection
(2) to the high-pressure hose con-
nection (3) on the equipment.
• Screw the gun side of the high-
pressure hose connection (1) to
the spray gun (10)
• Establish the water supply by
connecting the rapid-action wa-
ter supply connector to the water
connection with sieve insert (8).
C
• Connect to the spray gun (10)
by inserting and screwing in the
jet tube (11).
• If the jet pipe (11) is tted, screw
in with the jet pipe (11) to con-
nect either the adjustable fan
nozzle (12) or the high pressure
nozzle (13).
Screw in to connect the deter-
gent container with nozzle (14)
directly to the spray gun (10).
With using the cleaning agent
container with the nozzle (
A
14), pour only cleaning agent
into the container. It is sucked in
automatically.
The width of the jet can be increased by
turning the end of the nozzle to the left. To
reduce the width of the jet, turn the end of
the nozzle to the right.
