5. Technical data
Mains connection: 230 V ~ 50 Hz
Motor rating kW: 1.8 kW
Mode of operation S1
Compressor speed min
-1
: 2850
Operating pressure bar: max. 8
Pressure vessel capacity (in liters): 24
Theoretical suction power l/min.: approx. 270
Sound power level L
WA
in dB: 94
K
WA
uncertainty 4 dB
Protection type: IP20
Weight of the unit in kg: 26,5
Oil (15W 40) 0.3 l
6. Before starting the equipment
■ Check the equipment for damage which
may have occurred in transit. Report any
damage immediately to the transport
company used to deliver the compressor.
■ Install the compressor in the vicinity of the
point of consumption.
■ Avoid long air lines and supply lines
(extension cables).
■ Make sure that the intake air is dry and
dust-free.
■ Do not install the compressor in a damp or
wet room.
■ The compressor may only be used in
suitable rooms (with good ventilation and an
ambient temperature from +5 °C to 40 °C).
There must be no dust, acids, vapors,
explosive gases or inflammable gases in the
room.
■ The compressor is designed to be used in
dry rooms. It is prohibited to use the
compressor in areas where work is
conducted with sprayed water.
■ The oil level in the compressor pump has to
be checked before putting the equipment
into operation (see 9.4).
7. Assembly and starting
Important.
Remove the transportation braces
(between the compression pump and
cladding) prior to initial start-up. If the
transportation braces are not removed,
heat can build up and cause the
compressor to ignite.
Important.
You must fully assemble the appliance
before using it for the first time.
You will require the following tools for assembly
and installation:
2 x open-ended wrench size 13 mm (not
included)
7.1 Fitting the wheels (11)
Fit the supplied wheels as shown in Figure 5.
7.2 Fitting the supporting foot (8)
Fit the supplied supporting foot as shown in
Figure 6.
7.3 Fitting the air filter (15)
Remove the transportation stop (B) and screw
the air filter (15) to the equipment. (Fig. 7, 8).
7.4 Changing the transportation cover (A)
Remove the transportation cover from the oil
filler opening (21) and insert the supplied oil
sealing plug (16) into the oil filler opening. (Fig.
9,10).
7.5 Mains connection
■ The compressor is equipped with a mains
cable with shock-proof plug. This can be
connected to any 230V ~ 50 Hz shock-proof
socket which is protected by a 16 A fuse.
■ Before you use the machine, make sure that
the mains voltage complies with the
specifications on the rating plate.
■ Long supply cables, extensions, cable reels
etc. cause a drop in voltage and can
impede motor start-up.
■ In the case of low temperatures below
+5°C, motor start-up is jeopardized as a
11
GB
