Parkside PKO 270 A1 Operation And Safety Notes Original Operating Instructions

Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
Position Artikel-Nr. Beschreibung
1 401036001001 tank assy
2 401036001002 hexagon nut M8
3 401036001003 spring washer
4 401036001004 hexagon nut M8
5 401036001005 wheel assembly
6 401036001006 hex head screw M8 x 55
7 401036001007 wheel cover
8 401036001008 plug
9 401036001009 front housing
10 401036001010 tube assy
12 401036001012 fan
13 401036001013 rear motor cover hinten
14 401036001014 spring washer
16 401036001016 hex head screw M6 x 115
17 401036001017 spring washer
18 401036001018 stator assy
20 401036001020 capacitor 50æF
21 401036001021 externaltooth lock washer
22 401036001022 cross panhead screw M5 x 10
23 401036001023 hex flange screw M12
27 401036001027 hex head screw M8 x 30
29 401036001029 hex socket head cap screws M8 x 16 linksgewinde
30 401036001030 oil baffle plate
31 401036001031 breather assy
32 401036001032 crankcase cover
33 401036001033 oil leveler assy
34 401036001034 cross panhead screw M5 x 14
35 401036001035 handle
36 401036001036 cylinder gasket
37 401036001037 connecting rod
38 401036001038 piston
39 401036001039 oil clean ring
40 401036001040 cylinder
41 401036001041 valve plate gasket
42 401036001042 air inlet valve
43 401036001043 valve plate assy
44 401036001044 cylinder gasket
45 401036001045 right-angle connector
46 401036001046 cylinder head
47 401036001047 hex head screw M8 x 117
48 401036001048 air filter assy
49 401036001049 locating pin
50 401036001050 seal ring
51 401036001051 piston pin
52 401036001052 circlip
53 401036001053 safety valve assy
54 401036001054 pressure switch assy
55 401036001055 connector
56 401036001056 Pressure regulator assy
57 401036001057 Quick-lock coupling
58 401036001058 pressure gauge (eingestellter Druck)
59 401036001059 pressure gauge (Kesseldruck)
60 401036001060 lock nut M14
61 401036001061 discharge pipe assy
62 401036001062 non-return valve assy
63 401036001063 cord and plug
64 401036001064 drain valve für Kondenswasser
65 401036001065 supporting foot
66 401036001066 flat washer
67 401036001067 hex head screw M8 x 30
68 401036001068 pressure switch waterp. plug für Druckschalter
70 401036001070 cross panhead screw 3,5 x 25
71 401036001071 cross panhead screw M4 x 8
72 401036001072 externaltooth lock washer
73 401036001073 hexagon nut M4
74 401036001074 cross panhead screw
901 401036001901 crank case cpl. komplett
902 401036001902 motor cover cpl.
0 4138100 Air hose 6mm inner dia, 10m Air Compressor Accessory
0 401036001075 nut M8 M8
0 401036001076 washer 9x16x2 9 x 16 x 2
0 401036001077 spring washer
0 401036001078 cross screw 3,5x16 3,5 x 16
0 401036001079 cross screw M5x12 M5 x 12
0 401036001080 washer 5,5x10x1 5,5 x 10 x 1
