PLUNGE SAW PTSS1200C2
Introduction
Congratulations on the purchase of your new
appliance. You have chosen a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all the operating
and safety instructions. Use the product only as
described and for the range of applications speci-
fied. Please also pass these operating instructions
on to any future owner.
Intended use
This circular saw (hereinafter "appliance" or
"machine") is designed for longitudinal, cross and
plunge cuts in firmly supported solid wood, chip
board, plastics and lightweight construction materials.
Working with metals is not permitted. This appli-
ance can be used with the provided guide rails–
exclusively for the cutting techniques described.
Any other use of or modification to the appliance
is deemed to be improper and carries the risk of
serious personal injury. Not for commercial use.
Features
Safety lock-out
ON/OFF switch
Handle
Hex key (small)
Hex key (large)
Motor unit
Chip ejector adapter
Fine adjustment screws for 0° cutting angle
8a
Fine adjustment screw for 45° cutting angle
Base plate
9a
Cut line markings
Eccentric screw (2 x)
Adjustment wheel for cutting angle adjustment
(2 x)
Cutting depth adjustment
Cutting depth scale
Saw blade
14a
Clamping screw/washer
14b
Mounting cut-out
Additional handle
Cutting width marking
Chip ejector (rotatable)
Clamping lever for changing saw blades
Spindle lock
Groove for guide rails
Guide rail
Grub screws
Connector
X Flange (factory-fitted)
Package contents
1 plunge saw
1 saw blade 165mm/24 teeth (pre-fitted)
2 guide rails
1 connector
1 chip ejector adapter
2 hex keys
1 set of operating instructions
