EN
1 2 3
• Lower throttle and
throttle trim to
lowest settings.
• Connect battery
to ESC.
Continuous LED
Series of tones
Power on
Transmitter
Wait 5
seconds
Before Flight
Installing a Receiver
Battery Selection and Installation
1. Remove the canopy hatch to install a receiver.
2. Install your parkfl yer or full-range receiver on a shelf on the right side in the
fuselage using hook and loop tape or double-sided servo tape.
3. Attach the elevator and rudder servo connectors to the appropriate
channels of the receiver.
4. Attach the aileron Y-harness to the aileron channel of the receiver.
5. Attach the ESC connector to the throttle channel of the receiver.
1. We recommend the ParkZone 2200mAh 11.1V 25C Li-Po battery
(PKZ1029).
2. If using another battery, the battery must be at least a 25C
2100mAh battery.
3. Your battery should be approximately the same capacity, dimensions and
weight as the ParkZone Li-Po battery to fi t in the fuselage without changing
the center of gravity.
6
