WARNING!
Filtering System
The filter is used to avoid the big remnants and other sundries getting inside
the pump. The residue can obstruct the filter in sometime.
The filter system consists of a coarse filter, a flat
(Main filter) and a micro filter (fine filter).
1. Flat filter
Traps food and debris.
2. Coarse filter
Big debris, such as bone and glass that could clog the
drain will be trapped in the coarse filter.
To remove an item caught in this filter, gently squeeze
the taps on the top of this filter and lift it out.
3. Micro filter
This filter holds soiling and food residue in the sump
area and prevents it from being redeposit on the
dishes during a cycle.
- Inspect the filters for obstructions every time the
dishwasher has been used.
- By unscrewing the coarse filter, you can remove
the filter system. Remove any food remnants and
clean the filters under running water.
Step 1：Rotate the Coarse
filter anti-clockwise,
then lift it up;
Step 2：Lift the filter upFlat
7. Maintenance and cleaning
Filter assembly
For best performance and results, the filter assembly must be cleaned regularly. The filter efficiently
removes food particles from the wash water, allowing it to be recirculated during the cycle. For this
reason, it is a good idea to remove the larger food particles trapped in the filter after each wash cycle
by rinsing the semicircular filter and cup under running water. To remove the filter assembly, pull on
the cup handle in the upward direction. The entire filter assembly should be cleaned once a week.
To clean the coarse filter and the micro filter, use a cleaning brush. Then, reassemble the filter parts
as shown above and reinsert the entire assembly in the dishwasher, positioning in its
seat and pressing downward. The dishwasher must never be used without the filters. Improper
replacement of the filter may reduce the performance level of the appliance and damage dishes and
utensils.
Never run the dishwasher without the filters in place.
Cleaning the Spray Arms
It is necessary to clean the spray arms regularly for hard
water chemicals will clog the spray arm jets and bearings.
To remove the spray arms, screw off the nut clockwise to
take out the washer on top of the spray arm and remove the
arm. Wash the arms in soapy and warm water and use a soft
brush to clean the jets. Replace them after rinsing thoroughly.
Caring for the Dishwasher
To clean the control panel, use a lightly dampened cloth then
dry thoroughly.
To clean the exterior, use a non abrasive cleaner.
Never use sharp objects, scouring pads or harsh cleaners
on any part of the dishwasher.
Always dry the front panel after cleaning.
Protect Against Freezing
If your dishwasher is left in an unheated place during the winter, ask a service technical to:
1.Cut off electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter in the tub and the bottom and use a sponge to use up water in sump
Cleaning the Door
To clean the edge around the door, you should use only warm water and detergent on a soft
cloth. To prevent penetration of water into the door lock and electrical components, do not use a
spray cleaner of any kind.
Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch
the finish. Some papers towels can also scratch or leave marks on the surface.
2
1
3
1 2
To replace: Reverse the
removal process.
