2.Operation Instructions
2
Dishwasher Features
before using it for the first time.
To get the best performance from your dishwasher, read all the operating instructions
IMPORTANT
10
11
Back View
1
2
3
4
5
6
7
8
9
Front view
Lower basket
Dispenser
Cup shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Upper basket
Cutlery rack
Top spray arm
1
Inner pipe
5
6
7
8
9
11
10
3
2
4
Control Panel
1. On/Off Button: To turn On/Off the power supply.
3. Program indicators: To show which program is selected.
2. Program Button: To select the appropriate wash
program.
8. Start /Pause Button: To start the selected washing
program or pause when the
machine is working.
7. Dry + function: Press this button to select Extra drying
for your dishes.(
).
This function can only
be used with selected programmes:
Intensive, Heavy, Normal, Glass and
1 Hour
4. Delay Button: To delay the wash cycle.
5. 1/2 Wash Button: To wash only the upper basket or
the lower basket when loaded. Shows
which basket is selected .
6. Child lock function: To activate, press the Delay and
1/2 Wash button simultaneously for
more than 3 seconds. To unlock, use
the same method.
1
7
2
4
9
5
8
6
3 10
9. LED Display screen: Shows the remaining time
and status(running, delay time etc).
Rinse Aid indicator:
Indicates when the dispenser needs to be refilled.
Delay time, remaining time,or error codes indicator:
10. Indicators:
1/2 Wash function indicator:
Dry + indicator:
Child lock indicator:
Dry Plus: An increased temperature during the final
rinse stage will improve the drying process.
When this indicator lights on, it means that only the upper
spray arm and top spray arm will be running.Only the
upper basket and top cutlery basket have to be loaded.
When this indicator lights on, it means that only the lower
spray arm will be running, so you need to load only
the lower basket.
When both indicators light on, it means that both upper
and lower spray arms will be running, and you can load
both baskets.
1/2 Wash
Dry +
