26
BMW
A-iNstAllAtioN de lA CoNfigurAtioN CAN
• Connecter le fil vert correspondant au CAN High sur la voie 11.
• Connecter le fil Blanc correspondant au CAN Low sur la voie 9.
A- iNstAllAtioN de lA CoNfigurAtioN K-Bus
• Connecter le fil violet correspondant au K-Bus sur la voie 9.
Can Low
Can High
K-bus
Parrot
Can Low
Can High
K-bus
Parrot
CoNNeCteur BmW
CoNNeCteur BmW
