12
Car Stereo With line-in jaCkS (reFer to the FolloWing Diagram)
• Use this type of connection by wiring a line-out jack (brown & white wire or red & black wire) to your car stereo’s line-in jack.
• Using the two pairs of line-out jacks will enable you to take advantage of the streaming audio function in stereo over your vehicle’s speakers.
• On the installation cable, connect the free yellow wire to one of the audio system’s corresponding mute-in jacks if available (mute in 1, mute in 2 or mute in 3).
Note: the mute function is used to silence the sound from your car stereo to make way for a call. The choice of the mute-in jack
depends on your car stereo’s configuration.
Note: with this type of set-up, the original connectors of your vehicle’s audio system need not be removed.
