CD7220/CD3220 CUSTOMER DISPLAY
15
6.1.5 AEDEX mode command list
Command Code description (hex) Function description
! # 1 ....CR 21 23 31 [data x 40] upper line display
! # 2 ....CR 21 23 32 [data x 40] bottom line display
! # 4 ....CR 21 23 34 [data x 40] upper line message scroll continuously
! # 5 ....CR 21 23 35 hh ‘:’ mm 0D
h,m=‘0’-‘9’
display time
! # 6 ....CR 21 23 36 [data x 40] upper line message scroll once pass
! # 8 ....CR 21 23 38 n m 0D 20h<n,m change attention code
! # 9 ....CR 21 23 39 [data x 40] two line display
Table 6-7
6.1.6 DSP-800 mode command list
Command Code description (hex) Function descriptions
EOT SOH I n ETB 04 01 49 n 17 select international character set
EOT SOH P n ETB 04 01 50 n 17 n=31h-58h move cursor to specified position
EOT SOH C n m ETB 04 01 43 n m 17
31h<n<m<58h
clear display range from n position to m
position and move cursor to n position
EOT SOH S n ETB 04 01 53 n 17 n=31h-35h save current view message to n layer for demo view
data
EOT SOH D n m ETB 04 01 44 n m 17
n=31h-4Fh m=31h-33h
display the saved demo message
EOT SOH A n ETB 04 01 41 n 17 n=31h-34h brightness adjustment
EOT SOH F n ETB 04 01 46 n 17 00h<n<FFh blink display screen
EOT SOH & n [px5] ETB 04 01 26 n p1...p5 17, 20h<n define download characters
EOT SOH ? n ETB 04 01 3F n 17 20h<n delete download characters
EOT SOH = n ETB 04 01 3D n 17 select peripheral device
select printer n=‘1’, display n=‘2’
EOT SOH % ETB 04 01 25 17 initialize display
EOT SOH @ ETB 04 01 40 17 execute self-test
EOT SOH B n N ETB 04 01 42 n 4E 17 n=31h-36h set baud rate and parity
Table 6-8
(REMARK)
* International font set (Table 6-9)
n International font set
30h U.S.A.
31h France
32h Germany
33h U.K.
34h Denmark I
35h Sweden
36h Italy
37h Spain
38h Japan
39h Norway
3Ah Denmark II
